Operating Voltage:24VDC
Current Rating:10A @ 24VDC
Contact Rating:250VAC/110VAC, 10A @ 24VDC
Relay Type:SPST (Single Pole, Single Throw)
Contact Configuration:Silver-over-bronze contacts
Operating Ambient Temperature:-40°C to +85°C
Storage Temperature Range:-55°C to +125°C
Mechanical Life:50,000 cycles
Introducing the ABB 700DC-P800Z24, a cutting-edge industrial relay designed to meet the stringent demands of today’s manufacturing environments. With its robust construction and advanced features, this relay provides unparalleled reliability and precision control, essential for optimizing production lines.
Featuring an operating voltage of 24V DC, the 700DC-P800Z24 is compatible with a wide range of industrial automation systems, ensuring seamless integration. Its impressive contact rating supports heavy-duty applications without compromising on performance.
The relay’s operating temperature range from -20°C to +70°C ensures reliability across diverse environments, making it ideal for global applications. The SPDT (Single Pole Double Throw) design and CNO (Common Normally Open) contact form enable efficient circuit control, facilitating smooth operation in complex systems.
Equipped with a response time of less than 1 millisecond, the 700DC-P800Z24 ensures instantaneous switching under critical conditions, enhancing system responsiveness. Its IP20 protection class safeguards against dust and splashes, further enhancing its durability in industrial settings.
For ease of installation and maintenance, the relay employs a panel mount design, allowing quick integration into existing systems. The compact dimensions of 24mm in width, 30mm in height, and 16mm in depth make it space-efficient, while the lightweight design (15g) reduces overall system burden.
