AB MVI69-PDPMV1 Master Network Interface Module – Industrial Automation Solution

I/O Size:16-bit integers

Communication Parameters:{“Baud Rate”:”110 to 115K baud”,”Stop Bits”:”1 or 2″,”Data Size”:”7 or 8 Bits”,”Parity”:”None, Even, Odd”,”RTS Timing Delays”:”0 to 65535 milliseconds”}

Floating Point Data:Supports floating point data movement including configurable support for Enron, Daniel® and other implementations

Product Type:Network Interface Unit

Power Consumption:0.60 Amperes at 5 Volts DC

Ports:2

Compatibility:1769 backplane compatible

Memory Access:Processor memory access for data transfer

Data Transfer:Ladder Logic enabled for module and processor controller tags

Configuration:Uses ProSoft Configuration Builder Software for network setup

    This AB MVI69-PDPMV1 module is engineered to elevate industrial automation by providing robust and reliable communication capabilities. Its compatibility with various protocols ensures seamless integration with existing systems.

    With its 16-bit integer handling and adjustable communication parameters, it caters to a wide range of industrial needs, offering flexibility and precision in data transmission.

    The inclusion of floating point data movement and support for Enron, Daniel® and other implementations makes it a versatile choice for advanced control applications.

    Designed with an emphasis on user-friendliness, the module utilizes Ladder Logic for efficient data transfer between the module memory and the processor controller tags, simplifying complex programming tasks.

    Built with durability in mind, this module is backed by AB’s commitment to quality and performance, ensuring longevity and reliability in harsh industrial settings.
