Type:IGBT Module
Model:5SHX 1000H0003
Brand:ABB
Operating Temperature Range:-40°C to +125°C
Current Rating:1000A
Voltage Rating:600V
Insulation Resistance:≥10MΩ at 500V DC
Switching Frequency:Up to 16kHz
Power Dissipation:1200W
Package Size:WxHxD: 80mm x 100mm x 50mm
Cooling Method:Thermal Interface Material (TIM) and Forced Air Cooling
Unmatched Performance: Designed to deliver exceptional power handling capabilities in industrial automation systems, ensuring peak efficiency and reliability under extreme conditions.
Robust Construction: Utilizing advanced materials and manufacturing techniques, this IGBT module is built to withstand harsh industrial environments without compromising on performance.
Advanced Cooling System: Features an efficient thermal conduction system that ensures optimal heat dissipation, preventing overheating and enhancing the longevity of the module.
Wide Operating Range: Suitable for use across a broad temperature spectrum (-40°C to +125°C), making it ideal for applications in diverse geographical locations.
Simplified Installation: With its standard panel mount design, the ABB 5SHX 1000H0003 IGBT module simplifies installation processes, reducing downtime and increasing productivity.
