ABB AB 22A-D2P3N104 PowerFlex 4 AC Drive, High-Efficiency Variable Frequency Drive

Operating Voltage:480V AC

Phase:3

Power Rating:14 kW

Motor Horsepower:7.5 HP

Frame Size:C

Enclosure Type:Panel Mount – IP 20, NEMA/UL Type 1

Interface Module:Full Numeric LCD

Control Features:Standard control features with a full numeric LCD interface

Network Compatibility:Devicenet network type

Frame Types:Standard C, D, & E frames

Rating with Filtered Frames:Optional for Frames A & B

Manual:No manual equipped

Brake IGBT:Yes with Resistor: Yes

    The Allen-Bradley AB 22A-D2P3N104 PowerFlex 4 AC Drive boasts a compact design that seamlessly integrates into a variety of industrial settings, ensuring minimal footprint and maximum efficiency. It’s equipped with a high-resolution, full-numeric LCD interface that offers intuitive control, allowing operators to monitor and adjust drive parameters with ease.

    This AC drive is built with advanced control algorithms that enhance energy management and reduce overall system costs. Its robust construction ensures durability and reliability, making it suitable for demanding industrial environments where uptime is critical.

    Featuring a panel mount design with an IP 20 enclosure, this drive is protected against dust and non-corrosive liquids, ensuring optimal performance in diverse industrial settings. The inclusion of a full numeric LCD interface provides a comprehensive overview of system status, enabling quick troubleshooting and maintenance.

    With compatibility for Devicenet networks, the Allen-Bradley AB 22A-D2P3N104 facilitates seamless integration into existing factory automation systems. This feature allows for the sharing of data and commands between multiple devices, streamlining production processes and enhancing operational efficiency.

    The drive supports a range of frame types, including standard C, D, and E frames, offering flexibility in accommodating different motor sizes and power requirements. Additionally, the option for filtered frames (A & B) further enhances the drive’s compatibility with various industrial setups, ensuring a smooth and reliable operation.
