Module Type:ControlNet Communication Module
Compatibility:Compatible with Allen-Bradley ControlLogix Controllers
Data Rate:5 Mbps
Power Supply:24 VDC
Communication Distance:Up to 5000 ft (1524 m)
Environmental Rating:NEMA 4X / IP67
Operating Temperature:-40°C to +70°C (-40°F to +158°F)
Humidity Range:0% to 95%, non-condensing
Form Factor:Plug-in Module
Weight:0.5 lbs (0.23 kg)
The Rockwell Automation 1747-CP3 CompactLogix ControlNet Module is a robust and reliable component designed for industrial environments. It provides a high-speed communication interface for connecting multiple devices in a network.
With a data rate of 5 Mbps, this module ensures fast and efficient data transfer between PLCs and other system components. It supports up to 125 nodes, making it suitable for large-scale industrial applications.
The module operates within a wide temperature range of -40°C to +85°C, making it ideal for harsh industrial conditions. It is powered by a DC voltage supply ranging from 9 to 32 V, consuming approximately 1.2 watts.
This module is compactly designed with dimensions of 132.5 mm width, 76.2 mm height, and 87.5 mm depth, weighing approximately 0.5 kg. Its small footprint makes it easy to integrate into existing systems without taking up too much space.
The 1747-CP3 module comes with certifications such as CE, UL, and ATEX, ensuring compliance with international safety and quality standards. It is fully compatible with the CompactLogix series, providing seamless integration into industrial automation systems.
