B&R X20SI9100 Digital Input Module, Safe & Efficient Industrial Automation Solution

Module Type:Digital Input Module

Safe Digital Inputs:20

Pulse Outputs:4

Circuit Type:Sink

Software Input Filter:Configurable for each channel

Status Indicators:I/O function per channel, operating state, module status

Power Consumption (Bus):0.4 W

Power Consumption (Internal I/O):1.6 W

Nominal Voltage:24 VDC

Input Voltage Range:24 VDC -15% / +20%

    The B&R X20SI9100 Digital Input Module stands out for its robust design and high reliability. It is built with a sink circuit and offers a software input filter configurable for each channel, ensuring accurate and stable signal processing. The module is equipped with 20 safe type A digital inputs and 4 pulse outputs, making it a versatile choice for a wide range of industrial applications. Its nominal voltage of 24 VDC and input voltage range from -15% to +20% provide flexibility in various operational conditions. With a power consumption of 0.4W on the bus and 1.6W internally, this module is energy-efficient. The status indicators for I/O function per channel, operating state, and module status enhance ease of monitoring and maintenance. Installation is straightforward, allowing for quick setup and integration into existing systems.
