Operating Environment:Humidity up to 90% non-condensing
Weight:Approximately 5kg
Voltage Input:60 to 120V
Relay Dimensions:9”H, 7 ⅛”D, 7”W
Number of Logic Inputs:16
Fuse Type:.5 × 20 mm slow-blow Littelfuse
Analog Input Type:DC mA
Control Power Range:90 to 300 V DC; 70 to 265 V AC at 48 to 62 Hz
Windings Per Phase:3
Resistant Temperature Device (RTD) Type:3 wire; 100 Ω Nickel, 120 Ω Nickel, 100 Ω Platinum
Analog Output Maximum Load:10 kΩ at 0 to 1 mA, 600 Ω at 4 to 20 mA
Maximum Continuous Voltage Output:273 V
Display Type:40 character Enhanced LCD
Engineered for durability and reliability, the GE 745-W3-P5-G5-HI-A-L-R-E-H boasts an advanced LCD display that provides clear, real-time data on transformer status. The enhanced visibility ensures quick identification of operational anomalies.
With its robust design, this transformer management system is capable of withstanding overloads for 1 second at 80 times its rated current, and operates continuously at 3 times its rated current, offering unparalleled protection under extreme conditions.
Featuring dual windings per phase and versatile input options, this system is compatible with a wide range of transformer types and sizes, making it a flexible solution for diverse industrial applications.
Equipped with state-of-the-art RTD technology and a slow-blow fuse, the GE 745-W3-P5-G5-HI-A-L-R-E-H ensures rapid response to potential faults, minimizing downtime and maintenance needs.
The compact yet powerful design of this relay system allows for easy integration into existing industrial control networks, enhancing overall system efficiency and safety without compromising on functionality.
