Manufacturer:General Electric
Model:F31X134EPRBEG1
Series:531X
Board Number:531X134EPRBEG1
Code:FR00/0
Terminal Strip:Three-screw
Motor Speed Monitoring:Voltmeter compatibility
PI-tach Scale Adjustment:For 50% motor speed
Jumpers:Over 20
Resistor Network Arrays:Four
Potentiometers:Seven
Operating Temperature Range:-40°C to +70°C
Power Supply Voltage:12V DC
Input Current:≤ 15mA
Output Voltage:5V DC
Output Current:≤ 20mA
Memory Size:Not specified
Processing Speed:Not specified
The GE F31X134EPRBEG1 is a highly reliable encoder process interface board designed for compatibility with GE‘s DC-300 drives and other similar systems. It features a robust three-screw terminal strip for direct connection to motor control circuits, enabling accurate monitoring and adjustment of motor speeds without interference.
Equipped with over twenty jumpers, the board allows for fine-tuning of the PI-tach scale, optimizing performance across various operational scenarios. Four resistor network arrays and seven potentiometers provide additional flexibility for customization based on specific application requirements.
Operational in extreme environmental conditions, the F31X134EPRBEG1 withstands temperatures ranging from -40°C to +85°C, ensuring continuous functionality in diverse industrial environments. Its compact design and lightweight construction facilitate easy installation and maintenance.
The board is marked with a secondary number, 531X134EPRBEG1, and a code FR00/0 on one edge, facilitating identification and quick access to detailed technical documentation. Manuals from GE provide comprehensive guidance on schedules, installation procedures, and handling recommendations for optimal use.
Utilizing the F31X134EPRBEG1 enhances efficiency in industrial processes by ensuring precise motor speed control, reducing energy consumption, and improving overall system reliability. This makes it an indispensable component for modern industrial automation setups.
