Number of Setpoint Groups:4
Analog Input Impedance:375 Ω ± 10%
Case and Relay Weight:7.9 kg
Red Breaker Closed LED:Yes
Insulation Voltage:300 V
Manual:1601-0120-AE
Overvoltage Pickup Level:0 to 1.25 × VT in steps of 0.01
Waveform Capture Channels:4 currents, 3 voltages, 14 logic input states and 8 output relays
Time Overcurrent Protection:Extends distribution feeder life by shielding system components
Frequency Protection:Enhances reliability through adaptive frequency monitoring
Oscillography and Data Logging:Reduces troubleshooting times and simplifies system connections
Engineered for critical applications, the GE Fanuc SR750-P5-G5-S5-HI-A20-R-E is equipped with advanced features for efficient feeder management. This model offers precise control over distribution feeders, ensuring smooth operation and minimal downtime.
The relay’s robust design incorporates a multi-channel waveform capture capability, allowing for comprehensive monitoring of currents, voltages, and logic states. This feature provides detailed insights into system performance, enabling proactive maintenance and optimization.
With its enhanced faceplate option, the SR750-P5-G5-S5-HI-A20-R-E supports intuitive operation and easy integration into existing systems. The green breaker closed LED indicator ensures immediate visibility of the relay’s status, enhancing safety and operational efficiency.
Designed for long-term reliability, the product features a high insulation voltage, safeguarding against overvoltage conditions that could compromise system integrity. The manual guide offers comprehensive instructions for installation, configuration, and maintenance, ensuring a seamless user experience.
The GE Fanuc SR750-P5-G5-S5-HI-A20-R-E is a testament to the brand’s commitment to innovation and excellence in industrial automation. Its versatile functionality and user-friendly design make it an ideal solution for power distribution management in demanding environments.
