Manufacturer:General Electric
Model:HWA143-TDM-PMC-V20
Module Type:Data Acquisition Module
Input Channels:16
Output Channels:8
Sampling Rate:1 MHz
Resolution:16 bits
Communication Protocol:Ethernet/IP, Modbus TCP/IP
Power Supply:24 VDC
Operating Temperature Range:-40°C to +85°C
Dimensions:10 x 5 x 3 inches
Weight:2.5 lbs
Certifications:CE, UL, RoHS
The GE HWA143-TDM-PMC-V20 is meticulously engineered to meet the demanding requirements of modern industrial environments. Its core function lies in its ability to efficiently manage and process high-speed signals with exceptional precision and reliability. This module is designed to seamlessly integrate into existing TDM systems, offering an upgrade path for enhanced performance and functionality.
With 32 differential or 64 single-ended input channels, the HWA143-TDM-PMC-V20 can handle a wide range of signal types and volumes, making it suitable for complex data acquisition tasks. The module supports up to 1 MHz sampling rates per channel, ensuring real-time data processing without loss of fidelity.
The high-resolution 16-bit converter guarantees accurate signal representation, while its dynamic range of +/-10V allows for a broad spectrum of input signals. The module operates across a wide temperature range from -40°C to +85°C, ensuring reliable performance in harsh industrial conditions.
The HWA143-TDM-PMC-V20 is built with robust materials to withstand the rigors of industrial use, featuring a compact PMC form factor that facilitates easy integration into PCI-based systems. Its compatibility with both 3.3V and 5V power supplies makes it versatile for various system configurations.
In summary, the GE HWA143-TDM-PMC-V20 is a versatile and reliable solution for industrial data acquisition and processing needs, offering unparalleled performance and adaptability.
