Manufacturer:GE Industrial Systems
Series:Ex2100 Excitation Control
Part Number:IS200DSPXH1DBC
Functional Description:Digital Signal Processor Control Board
Functional Acronym:DSPX
PCB Coating:Conformal Coating
Functional Revision:1D
Artwork Revision:C
Instruction Manual:GEI-100488
Processor Speed:60 MHz
Interfaces:Two (Master or Slave) 5 Mb/s ISBus interfaces
The IS200DSPXH1DBC is a cutting-edge digital signal processor control board designed for excitation control systems. With its robust 60 MHz digital signal processor, it ensures precise and efficient control in industrial automation applications.
The board is equipped with an Application-Specific Integrated Circuit (ASIC), which enables it to handle specific tasks with higher efficiency and accuracy. This makes it ideal for applications where precision and reliability are paramount.
The conformal coating on the PCB provides excellent protection against environmental factors like humidity and dust, extending the lifespan of the board and ensuring consistent performance over time.
The onboard memory includes FLASH, RAM, and NVRAM, allowing for efficient data storage and retrieval. The inclusion of a boot loader ensures quick startup and easy firmware updates.
With two ISBus interfaces (Master or Slave), the IS200DSPXH1DBC can easily integrate into existing control systems or be configured as part of a networked solution. This flexibility makes it a versatile choice for a wide range of industrial control applications.
