OMRON E6H-CWZ3X Hollow Shaft Line Driver Encoder

Encoding Method:Incremental

Resolution:2500 P/R

Shaft Diameter:10 mm

Connection Type:Male connector, M12, 4-pin

Supply Voltage:10 V … 30 V

Operating Temperature:-20°C to +70°C

Material:Stainless Steel

Weight:Approx. 0.2 kg

IP Rating:IP67

    The OMRON E6H-CWZ3X Hollow Shaft Line Driver Encoder is designed for high-precision motion control applications. Its incremental encoding method provides accurate angular feedback, ensuring smooth operation and precise positioning.

    Featuring a compact hollow shaft design, this encoder is suitable for integration into a variety of machinery where space is limited. It ensures reliable performance even in challenging industrial environments.

    With its robust construction and wide operating temperature range, the E6H-CWZ3X is engineered to withstand harsh conditions typically encountered in manufacturing processes. This makes it an ideal choice for applications requiring high durability and reliability.

    The encoder’s NPN open collector output phase supports simple connection to various control systems, reducing setup time and complexity. The 1-meter cable length ensures flexibility in installation while minimizing signal degradation.

    Innovative design elements include advanced noise reduction technology, which enhances signal integrity and minimizes interference, leading to improved overall system performance. Additionally, the OMRON E6H-CWZ3X is compatible with a wide range of control modules, facilitating seamless integration into existing automation systems.
