Material Type:Cold-rolled silicon steel
Core Size (WxHxD):33.2 x 28 x 3 mm
Max Working Temperature:150°C
Inductance Range:20 μH to 200 μH
Operating Frequency:Up to 10 kHz
Permeability:4500
The Pioneer Magnetics PM3328B-6-1-3-E is meticulously designed to cater to the stringent requirements of modern industrial electronics. Its high-inductance value ensures minimal power loss and maximizes energy efficiency, making it ideal for power conversion and filtering applications.
Engineered with precision, this module boasts an extended temperature range from -40°C to +125°C, ensuring reliable performance across a wide variety of operational conditions. The use of Ferrite core material guarantees robust magnetic properties, ideal for high-frequency operations without compromising on performance.
With a maximum current rating of 10A and an insulation class of Class F, the PM3328B-6-1-3-E can handle high currents without overheating, providing a safer and more stable operation environment for sensitive electronic components.
Featuring a compact size of 33.2 x 28 x 1.0mm, this SMD (Surface Mount Device) module facilitates easy integration into space-constrained designs, enhancing system-level efficiency and footprint reduction.
Designed for durability and ease of use, the Pioneer Magnetics PM3328B-6-1-3-E is compatible with standard assembly processes and supports various mounting options, ensuring seamless integration into existing manufacturing lines. This versatile component is a game-changer for industries seeking to enhance their magnetic solutions with superior performance and reliability.
