Module Type:Profibus DPV1 Master
Product ID:MVI69-PDPMV1
Compatibility:Single-slot, 1769 backplane compatible
Memory Access:Input/Output module with access to processor memory
Data Transfer:Ladder Logic for data transfer between module memory and processor controller tags
Configuration:Sample ladder file included, configuration data from ProSoft Configuration Builder Software
Network Definition:Network definition provided by software for PROFIBUS network configuration
Communication Parameters:Flexible baud rate (110 to 115K), stop bits (1 or 2), data size (7 or 8 bits), parity (None, Even, Odd)
Timing Delays:Variable RTD timing delays (0 to 65535 milliseconds)
Floating Point Support:Supported, configurable for Enron, Daniel, and other implementations
Power Supply:220V AC power supply
Operating Frequency:30kHz
Certification:Certified product
Series Designation:Extended Module
The Prosoft MVI69-PDPMV1 PROFIBUS DPV1 Master Module is a high-performance solution for industrial automation, ensuring reliable communication and control in complex systems.
Designed with a single-slot compatibility for the 1769 backplane, this module seamlessly integrates into existing systems, enhancing operational efficiency without requiring major system modifications.
Recognized as an Input/Output module, it provides direct access to processor memory, enabling swift and secure data transfer between the module and the processor controller. This feature is particularly advantageous for real-time applications where speed and accuracy are paramount.
Leveraging Ladder Logic for data transfer between the module’s memory and the processor controller tags, users can easily configure and manage data flow according to their specific needs, streamlining development and maintenance processes.
Configurable through ProSoft Configuration Builder Software, the module allows for the definition of PROFIBUS networks, ensuring compatibility and reliability in various industrial settings. This flexibility supports diverse configurations, making it suitable for a wide range of applications.
With direct memory access capabilities, users can efficiently manage data exchange, reducing latency and improving overall system performance. The module’s robust design ensures durability and reliability in challenging industrial environments.
