I/O Size:0/120/240 – 16 bit integers
Communication Parameters:Baud Rate: 110 to 115K baud, Stop Bits: 1 or 2, Data size: 7 or 8 Bits, Parity: None, Even, Odd, RTS Timing delays: 0 to 65535 milliseconds
Floating Point Data Support:Movement supported for Enron, Daniel® and other implementations
Product Model:MVI69E-MBTCP
Module Type:Prosoft PLC
Version Compatibility:CompactLogix processors with 1769 I/O bus capability version 16 and greater (MicroLogix 1500 not supported)
Featuring licensed backplane technology, the Prosoft MVI69E-MBTCP module is manufactured under license from Rockwell Automation, ensuring high-speed data transfer between the module and CompactLogix/MicroLogix processors.
This enhanced communication module seamlessly integrates into your industrial automation system, providing a robust solution for managing complex data flow and enhancing system performance.
With support for RSLogix 5000, the MVI69E-MBTCP enables diagnostic data availability directly in controller tags, allowing for informed decision-making based on node health.
Utilizing an add-on instruction feature, the module creates UDTs (User Datagram Tables), which logically define input/output, status, and control data, streamlining system management and data handling.
Designed with a modular approach, the MVI69E-MBTCP supports floating point data operations, making it compatible with various industry standards and enhancing its versatility across different applications.
