Processor Type:32-bit RISC Processor
Processor Speed:64 MHz
Memory Capacity:NC 3 MB, PLC 128 KB
Operating System Memory:Battery-backed SRAM Memory
Interface Connections:Drive Interface, Measuring System Interfaces, PCMCIA Card Slot
Input Outputs:(4) 24V DC Digital Inputs, P-Switching, (1) NC READY Output, up to 2 Probes, up to 2 Electronic Handwheels
Software Compatibility:Prepared for PROFIBUS DP
The Siemens SINUMERIK 6FC5357-0BB25-0AA0 CNC Control Module boasts a 32-bit RISC processor, i960SB, which ensures fast processing speeds and efficient operation. The inclusion of an integrated floating point unit significantly enhances its computational capabilities for complex tasks.
Equipped with battery-backed SRAM memory for storing part programs and non-volatile data, this module ensures reliable operation even during power outages. The integrated Flash Memory supports the operating system and function software, providing a robust foundation for automation tasks.
With up to 4 drive interfaces for Analog Interface (+/-10V) and up to 4 Stepping Motor Drives, this control module offers flexibility and compatibility across various drive systems. The connection options for 1-Position Encoders via Incremental Position Measurement or SSI provide precise control over motion.
The presence of a PCMCIA card slot facilitates expansion and customization according to specific application requirements. The module features 4 x 24V DC digital inputs, supporting P-Switching, ensuring compatibility with a wide range of input devices. Additionally, it includes an NC READY output and support for up to 2 probes and electronic handwheels, enhancing its usability in diverse manufacturing environments.
Designed for integration into S7-300 housing, the Siemens SINUMERIK 6FC5357-0BB25-0AA0 CNC Control Module offers a compact and efficient solution for industrial automation. The integrated 24V DC power supply ensures stable operation without the need for external power sources, further simplifying installation and maintenance processes.
