Frequency Range:up to 50 MHz
Waveform Types:Sine, Square, Triangle, Ramp, Pulse, Arbitrary
Sampling Rate:1 GSa/s
Resolution:14-bit
Output Amplitude:20 Vpp into 50 Ohms
Phase Shift:+/- 1 degree
Interface:USB, LAN, GPIB
Memory Depth:16 kSa
Built-in Functions:FFT, Bode Plot
The Tektronix 5A48 Arbitrary Function Generator is designed for high-precision signal generation in demanding industrial environments. With its robust construction and advanced features, it provides unparalleled accuracy and reliability.
Key features include:
– Wide frequency range from 0.1 Hz to 50 MHz
– Multiple waveform types including sine, square, triangle, ramp, pulse, and arbitrary waveforms
– High amplitude range of ±10 Vp-p into 50 Ohms
– High-resolution output with 14-bit precision
– Two independent output channels for versatile signal generation
– Adjustable phase shift from 0 to 360 degrees
– Easy connectivity through USB, LAN, and GPIB interfaces
The Tektronix 5A48 is ideal for a variety of applications, including electronic test and measurement, industrial automation, and research and development. Its user-friendly interface and reliable performance make it a valuable tool for professionals in the field.
