Manufacturer:VISHAY
Model:120NQ045R
Type:Power MOSFET
On-Resistance:45 mΩ
Current Rating:120 A
Voltage Rating:450 V
Package:TO-247
Threshold Voltage:4 V
Thermal Resistance:1.2°C/W
The Vishay 120NQ045R is engineered for reliability and efficiency in demanding industrial environments. Its low on-state resistance ensures minimal power loss during operation, leading to higher energy efficiency and reduced operating costs.
With a high voltage rating of 450V and a robust current capacity of 120A, this MOSFET is capable of handling significant loads, making it suitable for a wide range of applications such as motor control, battery charging systems, and other power conversion tasks.
The Vishay 120NQ045R features a TO-247 package, known for its excellent thermal performance and ease of use in various circuit designs. This package type ensures reliable heat dissipation, allowing for safer and more efficient operation even under heavy load conditions.
This MOSFET is designed with a low threshold voltage of 3.0V (minimum), making it easy to drive with standard gate voltages. Additionally, its typical on-state resistance of 11.5mΩ guarantees low power loss, contributing to overall system efficiency.
For applications requiring high reliability and long-term stability, the Vishay 120NQ045R stands out due to its robust construction and high thermal resistance. With a thermal resistance of 0.6°C/W, it efficiently manages heat dissipation, ensuring stable operation over extended periods.
